Nordic Semiconductor

Nordic Semiconductor

Nordic Semiconductor specializes in ultra-low power wireless communication supporting Bluetooth low energy, Bluetooth Mesh, ANT+, 2.4GHz, IEEE 802.15.4, Thread, Zigbee and LTE-M/NB-IoT. The company's award-winning and highly flexible SoCs are employed by some of the world’s leading brands in a variety of IoT applications like beacons, smart home, wearables, as well as wireless keyboard and mouse, game controllers, sports equipment, toys and medical equipment.

Nordic's development tools provide developers with an ideal starting point and ready-built design framework to accelerate development of IoT products. Its software architecture features a unique and powerful separation between protocol stack and user application code providing application developers maximum flexibility, ease-of-development, and code safety.

Learn more at

Nordic Semiconductor supports OpenThread with their nRF5x family of SoCs and actively contributes to the ongoing development of OpenThread.

Important notice

Due to legal restrictions, support for hardware-accelerated cryptography utilizing ARM CryptoCell-310 is only available in mbedTLS library (libmbedcrypto.a) provided with the nRF5 SDK for Thread. The library available in the OpenThread repository does not support hardware acceleration. You can still use it, but the commissioning procedure takes much more time in such cases. For the best performance and user experience, use the library provided with the SDK.



The nRF52811 is a Bluetooth 5.1 Direction Finding SoC with comprehensive protocol support. It is the 4th addition to the nRF52 Series platform, extending the numerous applications and use cases already covered by the platform.

The nRF52811 SoC is capable of the latest and greatest features of Bluetooth 5.1, the most prominent being Direction Finding, taking Bluetooth positioning to new heights.

It is built around a 64 MHz Arm® Cortex™-M4 CPU, and has a range of digital peripherals and interfaces such as PDM, PWM, UART, SPI and TWI. It also has a capable 12-bit ADC. Exceptionally low energy consumption is achieved using a sophisticated on-chip adaptive power management system.

The radio in the nRF52811 SoC has comprehensive protocol capabilities, including Bluetooth 5.1 Directing Finding, all Bluetooth 5 features, 802.15.4, Thread, Zigbee, ANT and 2.4 GHz proprietary. It has 4 dBm TX power and has been optimized to offer the best RX sensitivity of all SoCs in the nRF52 Series.

Nordic Semiconductor nRF52811

More information



Thread Certified

The nRF52840 System-on-Chip (SoC) is an advanced, highly flexible, ultra-low power multiprotocol SoC ideally suited for ultra-low power wireless applications. It is particularly well suited for smart home and advanced wearable applications, including wearables for payment and medical purposes, as well as for industrial sensors and other Internet of Things (IoT) devices.

The nRF52840 SoC is built around a 32-bit ARM® Cortex™-M4F CPU with 1 MB flash and 256 kB RAM available on the chip. The embedded 2.4 GHz transceiver supports Bluetooth® low energy (Bluetooth 5), 802.15.4, ANT, and proprietary 2.4 GHz protocols. It is on air compatible with the existing nRF52 Series, nRF51 Series, and nRF24 Series products from Nordic Semiconductor.

Nordic Semiconductor provides full support for its platform within OpenThread and actively participates in the development of OpenThread by co-authoring the core of this stack.

OpenThread running on the nRF52840 is a Thread Certified Component.

Nordic Semiconductor nRF52840

More information
